| Brand Name : | CHONGYANG |
| Model Number : | CY-DROE-1000Liter/Hour |
| Certification : | ISO ,CE |
| Price : | Negotiation |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 100 Sets/Months |
| Delivery Time : | With 30-40 Days |
Product Name:How To Make Pharmaceutical Water Systems Work For You
Well, first of all, there’s very little guidance in terms of how to
build a water system exactly matching a particular application – in
other words, how do you make the water system best fit all the
users criteria? The simple answer is that usually you can’t, but
the designer has to use all their skills and experience to set out
the most appropriate scheme, i.e. the one with the ‘best fit’. Only
one of the seven answers will be the ‘best fit’, and you want to
make sure that’s the one you choose for your water system.
Matching the right water system to the production usage
requirements and expectations seems to be a common area of
difficulty. Often, pharmaceutical users don’t know what they
actually want, and are too ready and willing to accept a system
employing a basic, and limited ‘off the shelf’ design without fully
appreciating their own responsibilities as future owners to specify
and convey their exact requirements to the suppliers. Not too
difficult to see then, why many pharmaceutical companies struggle
with water systems that compromise their operation and efficiency.
Equally, not many water systems are ‘future-proof’ and even modest
changes and upgrades to facilities can soon compromise the fairly
rigid design and operation of a water system.
CHONGYANG WATER FEATURE:
CHONGYANG Water Spec. & Type
| Model | Effects | Capacity | Feed Water | Plant Steam | Cooling Water | Height (mm) | Length (mm) | Width (mm) |
| CY-WS100 | 4 | 100 | 115 | 45 | 80 | 2650 | 1300 | 710 |
| CY-WS200 | 4 | 200 | 230 | 76 | 120 | 2650 | 1360 | 710 |
| CY-WS200 | 5 | 200 | 230 | 62 | 50 | 2650 | 1620 | 710 |
| CY-WS300 | 4 | 300 | 345 | 109 | 190 | 2650 | 1410 | 730 |
| CY-WS300 | 5 | 300 | 345 | 89 | 90 | 2650 | 1730 | 730 |
| CY-WS500 | 4 | 500 | 575 | 185 | 310 | 3170 | 1680 | 900 |
| CY-WS500 | 5 | 500 | 575 | 148 | 130 | 3170 | 2000 | 900 |
| CY-WS750 | 4 | 750 | 865 | 256 | 300 | 3260 | 1680 | 900 |
| CY-WS750 | 5 | 750 | 865 | 205 | 178 | 3260 | 2000 | 900 |
| CY-WS1000 | 5 | 1000 | 1150 | 295 | 256 | 3685 | 2180 | 980 |
| CY-WS1000 | 6 | 1000 | 1150 | 245 | 65 | 3685 | 2830 | 980 |
| CY-WS1500 | 5 | 1500 | 1725 | 460 | 390 | 3685 | 2680 | 1100 |
| CY-WS1500 | 6 | 1500 | 1725 | 380 | 95 | 3685 | 3150 | 1100 |
| CY-WS2000 | 5 | 2000 | 2300 | 540 | 345 | 3940 | 3150 | 1100 |
| CY-WS2000 | 6 | 2000 | 2300 | 490 | 130 | 3950 | 3580 | 1100 |
| CY-WS3000 | 6 | 3000 | 3450 | 730 | 190 | 4050 | 4000 | 1200 |
| CY-WS4000 | 6 | 4000 | 3450 | 910 | 310 | 4800 | 4000 | 1200 |
| CY-WS5000 | 6 | 5000 | 5750 | 1140 | 440 | 4200 | 4550 | 1350 |

FAQ:
1.Question: Which process do you adopt ?
Answer:Usually we will be according to what your raw water quality and your requested water requirement .
2. Question:Can you customize For me?
Answer :Yes. We can manufacture according your requirement , we can even design appearance of equipment .
3.Question: What standards is the Pharmaceutical Purified Water System ?
Answer: Usually there are five standards in this pharmaceutical industry , FDA,cGMP ,GMP ,USP, Japanese .
4.Question:How long is the Delivery time ?
Answer: Usually the delivery time is 35 -40 Days .
|
